F plug Self-Install™ 4.9, 10 pcs. blister silver
€6.99*
€14.00
F plug Self-Install™ 4.9, 10 pcs. blister
4.9 Professional F male connector for tool-free assembly
%
€6.99*
€14.00
(50.07% saved)
incl. VAT.
- Professional 4.9 F-connector for tool-free installation, suitable for all coaxial cables with approx. 4.5 mm dielectric and 6.6–7.0 mm outer diameter
- The F self-install connector is a unique quality product developed, among other things, to replace the often lower-quality screw-on connectors used in DIY installations.
- Installation is simple and precise: Strip the cable and push on the connector – that’s all.
- Perfectly suitable for TechniSat coaxial cables: COAXSAT 140-4.6 and COAXSAT 120-4.6.
- Scope of delivery: 10 x F-connectors self-install 4.9 in blister pack
Pack: 10 piece
Professional installation for home - in seconds.
| Product Information | |
|---|---|
| EAN | 4019588103726 |
| Colour | silver |
| Item no. | 0010/3372 |
| Device (W x H x D) | 1 x 1 x 1 cm |
| Box | 1 x 1 x 1 cm |
| Attenuation | |
|---|---|
| 10 MHz | 0,01 |
| 100 MHz | 0,01 |
| 450 MHz | 0,02 |
| 862 MHz | 0,04 |
| 1000 MHz | 0,06 |
| 2250 MHz | 0,06 |
| Return loss | |
|---|---|
| 30 - 65 MHz | ≥ 38 dB |
| 65 - 470 MHz | ≥ 38 dB |
| 470 - 1800 MHz | ≥ 26 dB |
| 1800 - 2450MHz | ≥ 26 dB |
| Shielding | |
|---|---|
| 30 - 1000 MHz | > 120 dB CoMeT |
| 1000 - 2250 MHz | > 110 dB CoMeT |
| Technical data | |
|---|---|
| Impedance | 75 Ω |
| Transfer impedance | |
|---|---|
| 5MHz | < 4 CoMeT |
| 30 MHz | < 4 CoMeT |
