Zwischenverstärker 4Z-WB silver/yellow
€149.00*
Zwischenverstärker 4Z-WB
4-way line amplifier
€149.00*
incl. VAT.
- Compensates for the attenuation of 80 meters of RG6 cable
- Frequency range: 250 - 2400 MHz
- Adjustable gain (max. 30 dB at 2400 MHz)
- Slope adjustable 0 - 8 dB
- For 2 wideband LNBs or 1 Quattro LNB
Line Amplifier 4Z-WB, power supply, instruction manual
Broadband repeater for 4 trunk lines.
The intermediate amplifier 4Z-WB operates in the frequency range of 250 ... 2,400 MHz and is ideally suited to amplify signals from two wide-band LNBs and to compensate the electrical losses of up to 80 meters RG6 cable. Each of the 4 amplifiers has a separately adjustable level and slope correction.
Power is supplied by an external power supply (included in delivery).
The amplifier is approved exclusively for indoor installation.
The intermediate amplifier 4Z-WB operates in the frequency range of 250 ... 2,400 MHz and is ideally suited to amplify signals from two wide-band LNBs and to compensate the electrical losses of up to 80 meters RG6 cable. Each of the 4 amplifiers has a separately adjustable level and slope correction.
Power is supplied by an external power supply (included in delivery).
The amplifier is approved exclusively for indoor installation.
You are free to install the software updates provided by TechniSat. However, TechniSat expressly points out that we are not liable for material defects that are solely due to the fact that you did not install the updates within a reasonable time, although TechniSat had informed you of their availability and provided you with a flawless installation guide.
| Product Information | |
|---|---|
| EAN | 4019588032446 |
| Colour | silver/yellow |
| Item no. | 0000/3244 |
| Weight (Box) | 680 g |
| Weight | 450 g |
| Device (W x H x D) | 15 x 10,5 x 3,7 cm |
| Box | 24 x 12,5 x 5 cm |
| Ambient operating conditions | |
|---|---|
| Humidity | 10 - 75 % |
| Ambient temperature | -25 bis 55 °C |
| Amplification | |
|---|---|
| Sat | 18 - 30 dB |
| Decoupling | |
|---|---|
| Trunks | 40 dB |
| General characteristics | |
|---|---|
| Top features | Compensates the attenuation of 80 meters of RG6 cable |
| Top features | Frequenzbereich: 250 - 2400 MHz |
| Top features | Verstärkung einstellbar (max. 30 dB bei 2400 MHz) |
| Top features | Schräglage einstellbar 0 - 8 dB |
| Top features | Für 2 Wideband-LNBs oder 1 Quattro-LNB |
| Power supply | |
|---|---|
| Nominal voltage | 230 V DC |
| Frequency | 50 Hz |
| Mains adapter | external (DC 12 V / 2,0 A) |
| Power consumption | typ. 560 mA @12V |
| Reception range | |
|---|---|
| Sat | 250 - 2.400 MHz |
| Technical data | |
|---|---|
| Satellite inputs | 4 |
| Distribution length | 80 m |
