TECHNIVISTA 65 titanium
A
G
G
G
€1,655.00*
€1,699.00
PRODUCT NO LONGER AVAILABLE
TECHNIVISTA 65
(5565/9810)
65 inch / 164 cm UHD / 4K Smart TV with triple TwinTuner.
You are free to install the software updates provided by TechniSat. However, TechniSat expressly points out that we are not liable for material defects that are solely due to the fact that you did not install the updates within a reasonable time, although TechniSat had informed you of their availability and provided you with a flawless installation guide.
| Product Information | |
|---|---|
| Weight without stand | 18 kg |
| EAN | 4019588658103 |
| Colour | titanium |
| Item no. | 5565/9810 |
| Weight (Box) | 25,61 kg |
| Weight | 18,25 kg |
| Unit without stand (W x H x D) | 145,5 x 83 x 7,5 cm |
| Device (W x H x D) | 145,5 x 88,5 x 33,5 cm |
| Box | 163,5 x 101,5 x 15 cm |
| TechniSat added value services | |
|---|---|
| SFI+ | Yes |
| ISI-Mode | Yes |
| TECHNIFAMILY | Yes |
| ISIPRO | Yes |
| AUTOINSTALL | Yes |
| TECHNIMATIC | Yes |
| Multimedia | |
|---|---|
| DVR function | Yes |
| DVR storage medium | USB, NAS |
| Timeshift | Yes |
| Recordings edition function | Yes |
| Recordings folder management | Yes |
| Streaming of recordings | Yes |
| WLAN | |
|---|---|
| 2,4 GHz | Yes |
| 5 GHz | Yes |
| IEEE 802.11n | Yes |
| IEEE 802.11g | Yes |
| IEEE 802.11b | Yes |
| IEEE 802.11a | Yes |
| WPA2 | Yes |
| WPA | Yes |
| WEP | Yes |
| WLAN | integrated |
| Ambient operating conditions | |
|---|---|
| Humidity | 10 ... 75 % |
| Ambient temperature | 5 ... 35 °C |
| LNB control | |
|---|---|
| Vertical | 14 V |
| Horizontal | 18 V |
| Band switch | 22 kHz |
| Current consumption | max. 400 mA (short-circuit proof) |
| DiSEqC | 1.0 / 1.2 / SCR1 = EN50494, SCR2 = EN50607 |
| Internet/Network | |
|---|---|
| Internet | Yes |
| ISIO Internet | Yes |
| HbbTV | Yes |
| VoD services | Yes |
| Webbrowser | Yes |
| HTML 5 support | Yes |
| Internet speed test | Yes |
| Audio | |
|---|---|
| HDMI ARC | Yes |
| Output power (W) | Sinus power (1 kHz): 2 x 10W @ THD+N < 1% |
| Power and energy consumption | |
|---|---|
| Supplier’s name or trade mark | TechniSat |
| Supplier’s address | TechniSat Digital GmbH, Julius-Saxler-Str. 3, 54550 Daun |
| Model identifier | 5565/9810 |
| Energy Efficiency Class for standard Dynamic Range (SDR) | G |
| On mode power demand for Standard Dynamic Range (SDR) | 119 W |
| Standby mode power demand, if applicable | 0,4 W |
| Electronic display category | Fernsehgerät |
| Size ratio | 16:9 |
| Screen resolution (pixels) | 3840 x 2160 |
| Screen diagonal | 163,9 cm |
| Screen diagonal | 65 in |
| Visible screen area | 114,8 dm² |
| Panel technology used | LED-LCD |
| mage refresh frequency rate (default) | 50 Hz |
| Minimum guaranteed availability of software andfirmware updates (from the date of end of theplacement on the market) | 8 Jahre |
| Minimum guaranteed availability of spare parts (fromthe date of end of the placement on the market) | 7 Jahre |
| Minimum guaranteed product support | 8 Jahre |
| Minimum duration of the general guarantee offeredby the supplier | 2 Jahre |
| Power supply type: | Intern |
| Bluetooth Version & Profile | |
|---|---|
| Bluetooth version | 2.1 / 3.0 / 4.0 |
| A2DP (Advanced Audio Distribution Profile ) | Yes |
| Connections | |
|---|---|
| HDMI™ (in) | 4 (4K 50/60p / HDCP 2.2) |
| Audio return channel (ARC) | Yes |
| USB | 2 (USB 3.0) |
| Digital optical audio out | Yes |
| Ethernet 1Gbit/s (RJ-45) | 1 |
| F socket | 2 |
| IEC-Connector | Yes |
| Audio out analogue (3,5 mm jack) | 1 |
| Headphone output | Yes (3,5mm jack) |
| Decryption system | |
|---|---|
| CI+ | Yes (2x) |
| Display | |
|---|---|
| Type | UHD Direct-LED |
| Resolution (vertical and horizontal) | 3840 x 2160 |
| Size (cm) | 164 cm |
| Size (inches) | 65 |
| UHD | Yes |
| UHD/4K upscaling | Yes |
| HD | Yes |
| SD | Yes |
| 2160p | Yes |
| 1080p | Yes |
| 1080i | Yes |
| 720p | Yes |
| 576p | Yes |
| 576i | Yes |
| 480p | Yes |
| 480i | Yes |
| Angle of view | 178° / 178° |
| Format | 16:9 |
| Picture in Picture (PIP) | Yes (2x SD, 2x HD, 1x UHD u. 1x HD, 1x UHD u. 1x SD, 1x SD u. 1x HD) |
| Picture and Picture (PAP) | Yes (2x SD, 2x HD, 1x UHD u. 1x HD, 1x UHD u. 1x SD, 1x SD u. 1x HD) |
| Zoom | Yes |
| Freeze frame | Yes |
| Handling/comfort | |
|---|---|
| Smart Home client | Yes |
| Electronic Program Guide (EPG) | Ja |
| Voice control | Yes |
| Quick start | Yes |
| Parental Control | Ja |
| Media Player | Yes |
| Export database | Yes |
| Channel number mix | Yes |
| Teletext | Yes |
| Alarm | Yes |
| Autostandby | Yes |
| Sleep timer | Yes |
| Hotel mode | Yes |
| Clock | Yes |
| Hotel mode | |
|---|---|
| Protected access to hotel mode | Yes |
| Customisable start screen | Yes |
| Energy card function | Yes |
| USB cloning function | Yes |
| Multimedia connectors | Yes |
| Lockable volume | Yes |
| Menu locking | Yes |
| Control panel lock | Yes |
| Radio mode | Yes |
| Alarm function | Yes |
| Sleep timer | Yes |
| Mixing of channel slots | Yes |
| Multicode remote control | Yes |
| Selectable start source | Yes |
| Selectable start channel | Yes |
| Other features | |
|---|---|
| OSD languages | English, German, French, Greek, Italian, Dutch, Polish, Portuguese, Russian, Swedish, Spanish, Czech, Turkish, Hungarian |
| Total programme memory | 9.999 |
| Regional channel selection | Yes |
| Power consumption | |
|---|---|
| Model designation | TECHNIVISTA 65 |
| Energy class | A |
| Visible screen size (cm) | 164 |
| Visible screen size (inches) | 65 |
| In operation | 134 W |
| annual energy consumption when switched on | 196 kilowatt hour per annum |
| Standby | 0,48 W |
| Power supply | |
|---|---|
| Nominal voltage | 230 V |
| Frequency | 50 Hz |
| Mains adapter | internal |
| Streaming | |
|---|---|
| DLNA Server | Yes |
| DLNA Client | Yes |
| Cloud store | Yes |
| Parental Control | Yes |
| TechniCast | Yes (optional with Dongle) |
| Supported formats & codecs | |
|---|---|
| Video-Codecs | MPEG-2, MPEG-4, H.264 (bis H.264/AVC Level 4.2), H.265, DivX, VC-1 |
| Video-Formats | M4V, MP4, MKV, MOV, MPG, TS, TS4, VOB, WMV, Xvid, M2V, M2TS, AVI, ASF |
| Picture-Formats | BMP, JPEG, GIF, PNG, TIFF |
| Audio-Formats | WAV, MP3, AAC, FLAC, M4A, MP2, OGG, DDAC3, WMA |
| TechniSat CONNECT | |
|---|---|
| SFI | Yes |
| Tuner | |
|---|---|
| Tuner type | 3 x Twin-Tuner |
| Twin-Tuner | Yes |
| Reception on | UHD ( H.265/HEVC), HDTV (MPEG-4), SD (MPEG-2) |
| DVB-S tuner | 2 |
| Single Cable Solution (SatCR) | SCR1 = EN50494, SCR2 = EN50607 |
| DVB-C Tuner | 2 |
| Tuner DVB-T2 | 2 |
| Satellite radio | Yes |
| Pay TV enabled | Yes |
| Cable radio | Yes |
| Internet radio | Yes |
| Input impedance | 75 Ω |
| TECHNIROUTER ready | Yes |
| TECHNISELECT 12 ready | Yes |
| Tuner - Cable | |
|---|---|
| Reception range | 47 ... 862 MHz |
| Demodulation | 16-, 32-, 64-, 128-, 256-QAM |
| Symbol rate | 1,5 ... 7,2 |
| FEC | Reed-Solomon (204, 188) |
| Tuner - Sat | |
|---|---|
| Reception range | 950 ... 2.150 MHz |
| DVB-S | QPSK |
| DVB-S | 2 ... 45 (MCPC / SCPC) |
| DVB-S2 | 8PSK - QPSK |
| DVB-S2 | 10 ... 31 (MCPC / SCPC) |
| FEC | RS, LDPC, BCH |
| Tuner - Terrestrial | |
|---|---|
| Reception range 1 | 174 ... 230 MHz |
| Reception range 2 | 470 ... 862 MHz |
| Demodulation | COFDM (QPSK, 16-QAM, 64-QAM) |
| Transmission mode | 2k/8k |
| Bitrate | 4,98 ... 31,67 |
| FEC | 1/2, 2/3, 3/4, 5/6, 6/7, 7/8 |
| Voltage supply | 5 V |
| Power supply | 0,03 A |
| wall bracket | |
|---|---|
| VESA wall mounting standards | 400 x 200 |
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
