GIGASWITCH 9/8 G2 blue/yellow
€229.00*
€239.99
PRODUCT NO LONGER AVAILABLE
GIGASWITCH 9/8 G2
(0000/3245)
Multi-switch system with option of 8 IF level and a terrestrial input for distribution to up to 8 participants
| Product Information | |
|---|---|
| EAN | 4019588032453 |
| Colour | blue/yellow |
| Item no. | 0000/3245 |
| Weight (Box) | 1,1 kg |
| Weight | 400 g |
| Device (W x H x D) | 21,7 x 11,7 x 3,3 cm |
| Box | 22,5 x 9,9 x 12,3 cm |
| Ambient operating conditions | |
|---|---|
| Ambient temperature | -25 ... 55 °C |
| Amplification | |
|---|---|
| Sat | -2 ... 3 dB |
| Terrestrial | -4 ... -1 dB |
| Decoupling | |
|---|---|
| Output | > 35 dB |
| Trunks | 40 dB |
| General characteristics | |
|---|---|
| Top features | Ausbaufähig mit bis zu 4 Kaskaden |
| Top features | Stromsparschaltung |
| Top features | Ohne Dämpfung im Sat-Bereich |
| Top features | Mit Schräglagenentzerrung |
| Top features | Für 2 Quatro-LNB |
| Power supply | |
|---|---|
| Nominal voltage | 15 V DC |
| Mains adapter | external |
| Reception range | |
|---|---|
| Sat | 950 ... 2.150 MHz |
| Terrestrial | 47 ... 862 MHz |
| Technical data | |
|---|---|
| Satellite inputs | 8 |
| Terrestrial input | 1 |
| Outputs | 8 |
| Distribution length | 100 m |
