TECHNIROUTER MINI 2/1x2 silver/yellow
€69.00*
TECHNIROUTER MINI 2/1x2
Expand an existing cable derivation into a Twin solution or into a two-subscriber solution without laying additional cables
€69.00*
incl. VAT.
- Twin reception or supplying two satellite receivers with only one cable. Router for expanding an existing cable branch into a twin or two-subscriber solution without laying new cables
- The TechniRouter Mini 2/1x2 uses Satellite Channel Router (SCR) technology. The connected satellite receivers or TV sets with integrated satellite tuner must support the EN 50494 standard
- The router can only be connected to two existing free subscriber lines of a multiswitch or a twin or quad switch LNB. It is not suitable for Quattro LNB
- The PIN code technology of the single-cable solution enables access protection on compatible receivers. Power is supplied via the receiver/TV. Quality Made in Germany
- Scope of delivery: TECHNIROUTER MINI 2/1x2 and mounting instructions, power supply optionally available (item no. 0001/3289), product dimensions (WxHxD): 5 x 2.8 x 11.5 cm
TechniRouter Mini 2/1x2, Manual
Twin reception with just a single cableFor extending an existing cable feed into a Twin solution or into a two subscriber solution.
The TechniRouter Mini allows you to continue to provide your TechniSat hard disk receiver or digital satellite TV with an integrated digital video recorder via a single-cableand watch other programmes while recording.
One cable, two satellite receivers
Your own satellite connection in your apartment can be extended in no time to create a second connection or, in a digital satellite household, multiple TV sockets can be connected to each other via a single cable.
Reception of standard digital, HDTV, digital antenna (DVB-T) and VHF in one
The TechniRouter Mini allows trouble-free reception of the entire range of digital programming in standard digital or HDTV channels. If the relevant reception signals are received, the TechniRouter Mini supplies digital antenna (DVB-T) VHF to all connected TV sockets.
Up to two orbit positions
The TechniRouter Mini allows Twin reception of up to two orbit positions, such as ASTRA 19° East and Eutelsat Hotbird 13° East, which is unique and uses just one cable.
How does it work?
The TechniRouter Mini 2/1x2 is connected to 2 outputs on an existing multiswitch installation or a LNB. It generates two SCR frequencies (1284 MHz and 1400 MHz), thus enabling a Twin function solution. The TechniRouter Mini can be used with any receiver that is TechniRouter ready or can meet EN 50494.
PIN code technology
The new PIN code technology makes the issue of subscriber frequencies even more secure. This means that unauthorised access by another subscriber to your frequency is thus impossible. This function must be supported by special receivers. Please look out for the “PIN Code Technology” logo.
You are free to install the software updates provided by TechniSat. However, TechniSat expressly points out that we are not liable for material defects that are solely due to the fact that you did not install the updates within a reasonable time, although TechniSat had informed you of their availability and provided you with a flawless installation guide.
| Product Information | |
|---|---|
| EAN | 4019588032897 |
| Colour | silver/yellow |
| Item no. | 0000/3289 |
| Weight (Box) | 400 g |
| Weight | 200 g |
| Device (W x H x D) | 5 x 2,8 x 11,5 cm |
| Box | 18 x 4 x 18,5 cm |
| sonstiges | |
|---|---|
| bf_filter_digital_single_cable_solution | Yes |
| bf_filter_number_of_participants | 2 |
| Ambient operating conditions | |
|---|---|
| Humidity | 10 ... 75 % |
| Ambient temperature | -25 ... 55 °C |
| Amplification | |
|---|---|
| Sat | 2 dB |
| Terrestrial | -3 dB |
| Decoupling | |
|---|---|
| Trunks | 30 dB |
| General characteristics | |
|---|---|
| Top features | Expansion of coaxial line to twin function |
| Top features | No additional cable routing required |
| Top features | 2 adjustable orbit positions |
| Top features | Very compact dimensions |
| Top features | Can be connected behind Twin, Quatro Switch LNB and multiswitch |
| Top features | Terrestrial outlet for DVB-T(2)/UHV |
| Power consumption | |
|---|---|
| In operation | max. 2 W (Standby 0 W) |
| Power supply | |
|---|---|
| Nominal voltage | 230 V |
| Mains adapter | extenal 12 VDC/1,5 A |
| Frequency | 50 Hz |
| Reception range | |
|---|---|
| Sat | 950 ... 2.150 MHz |
| Terrestrial | 47 ... 862 MHz |
| Single-cable output | |
|---|---|
| Output frequency | 47 ... 2.150 MHz |
| Number of output channels | 2 |
| Frequency of the output channels | 1284, 1400 MHz |
| Frequency SAT | 1.250 ... 1.430 MHz |
| Frequency DVB-T | 47 ... 862 MHz |
| Output level | - 3 dB |
| Technical data | |
|---|---|
| Satellite inputs | 2 |
| Number of cable connections | 1 |
| Subscribers per cable | 2 |
