Universal-Twin-LNB black
€32.00*
Universal-Twin-LNB
Digital LNB with 2 legacy outputs
€32.00*
incl. VAT.
- Reception for up to two users: the Twin LNB can supply up to two devices (receiver/TV) with satellite signal; program selection is independent. Expansion via multiswitch is not possible
- One orbital position: The LNB receives signals from a single orbital position, typically Astra 19.2° East in Germany
- Universally usable: The LNB fits all satellite dishes with a 40 mm feed clamp and can be easily installed or replaced
- Interference-free reception: The LNB is protected from LTE mobile interference by its design
Universal-Twin-LNB
The LNB is suitable for all satellite dishes with a 40 mm feedhorn and is used to receive TV, radio, and multimedia services broadcast via satellite. The LNB has two outputs, each of which can be directly connected to a receiving device (satellite receiver or smart TV). All receiving devices are independent in their choice of channels, as the signals from the entire reception range are available at each of the two LNB outputs. A twin receiver can also be connected to the universal twin LNB instead of two separate devices. Due to its design, the universal twin LNB is protected against interference from LTE mobile networks.
| Product Information | |
|---|---|
| EAN | 4019588083820 |
| Colour | black |
| Item no. | 0000/8382 |
| Weight (Box) | 170 g |
| Weight | 138 g |
| Device (W x H x D) | 5,4 x 10,1 x 13 cm |
| Box | 10,6 x 13,8 x 6,1 cm |
| Local oscillator | |
|---|---|
| Low band | 9,75 GHz |
| High band | 10,6 GHz |
| Accuracy | ± 1 MHz |
| Temperature drift | ± 1 MHz |
| Phase noise | -75 @10kHz |
| Filter-Navigation | |
|---|---|
| Number satellites | 1 |
| Number participants | 2 |
| LNB control | |
|---|---|
| Vertical | 11,5 ... 14,5 V |
| Horizontal | 16 ... 19 V |
| Band switch | 22 kHz |
| Ambient operating conditions | |
|---|---|
| Humidity | 10 ... 95 % |
| Ambient temperature | -40 ... 70 °C |
| Input frequency range | |
|---|---|
| Low band | 10,7 ... 11,7 GHz |
| High band | 11,7 ... 12,75 GHz |
| Noise factor | |
|---|---|
| Noise figure | typ. 0,9 dB |
| Output frequency range | |
|---|---|
| Low band | 950 ... 1.950 MHz |
| High band | 1.100 ... 2.150 MHz |
| Power supply | |
|---|---|
| LNB voltage supply | 11,5 ... 19 V |
| Power consumption | max. 140 mA |
| Prepared for | |
|---|---|
| Number of clients | 2 |
| Number of orbit positions | 1 |
| Technical data | |
|---|---|
| Feed reception | 40 mm |
| Outputs | 2 |
| Amplification | 58 ... 64 dB |
| Impedance | 75 Ω |
| Connector type | F female |
