100 dB COAX 10 direct-burial cable, 100 m ring black
€299.00*
100 dB COAX 10 direct-burial cable, 100 m ring
High-end 3-way shielded RG11 buried coaxial cable , 100 dB screening
€299.00*
incl. VAT.
Content:
100 meter
(€2.99 / 1 meter)
This product is manufactured in Germany and represents the highest quality standards. Precise workmanship and strict controls ensure long-lasting reliability.
This 100 dB underground cable, type 1.6/7.3, is particularly suitable for use in larger distribution systems. These can be GA/GGA or satellite IF distribution systems. Due to its high shielding effectiveness, achieved through triple shielding, this cable is ideally suited for use in large distribution systems, even within buildings. Furthermore, its extremely low attenuation values allow the underground cable to be used even over longer distances, as transmission losses remain minimal. The cable is available in 100 m, 250 m, or 500 m lengths. Suitable F-crimp connector: 0000/3410
| Product Information | |
|---|---|
| Coil length | 100 m |
| EAN | 4019588130166 |
| Cable length | 100 m |
| Colour | black |
| Item no. | 0010/3016 |
| Weight (Box) | 9,53 kg |
| Weight | 8,5 kg |
| Device (W x H x D) | 42 x 42 x 15 cm |
| Box | 55 x 45 x 40 cm |
| Attenuation | |
|---|---|
| 100 MHz | 4,1 |
| 200 MHz | 6,9 |
| 450 MHz | 9,6 |
| 800 MHz | 12,6 |
| 1000 MHz | 14,8 |
| 1350 MHz | 18,3 |
| 1750 MHz | 21,1 |
| 2050 MHz | 23,9 |
| 2250 MHz | 26,1 |
| Return loss | |
|---|---|
| 65 - 470 MHz | ≥ 23 dB |
| 470 - 1800 MHz | ≥ 21 dB |
| 1800 - 2450MHz | ≥ 20 dB |
| Technical data | |
|---|---|
| Frequency range | 5 ... 2.600 MHz |
| Impedance | 75 Ω (± 3) |
| Inner cable diameter | 1,6 mm |
| Inner cable material | Copper bare |
| Isolation | Zell-PE |
| Diameter dielectric | 7,3 mm (± 0,1) |
| Outer cable | 1 x Alum. foil + 1 x tinned copper braiding 25 x 5 x 0.172 mm + 1 x Alum. foil |
| Sheath | PE, black |
| Diameter with coating | 10,3 mm (± 2) |
| Bending radius | ≥ 110 mm |
| Coupling resistance | ≤ 3 @ 5 MHz |
| Capacity | 55 pF |
| Shrinkage factor | 0,81 |
| Shielding factor | ≥ 100 dB ≙ Klasse A |
| Transfer impedance | |
|---|---|
| 5MHz | ≤ 3 |
| 30 MHz | ≤ 0,1 |
