GIGASWITCH 9/20 LAN blue/yellow
€280.00*
€289.00
PRODUCT NO LONGER AVAILABLE
GIGASWITCH 9/20 LAN
(0000/3256)
Compact multiswitch for 20 participants for distribution of 2 orbit positions, terrestrial signals and TechniLAN support
| Product Information | |
|---|---|
| Colour | blue/yellow |
| EAN | 4019588032569 |
| Item no. | 0000/3256 |
| Weight (Box) | 1,05 g |
| Weight | 450 g |
| Device (W x H x D) | 17,4 x 3,3 x 15 cm |
| Box | 26,5 x 5,7 x 15,5 cm |
| Filter-Navigation | |
|---|---|
| Number participants | 20 |
| Ambient operating conditions | |
|---|---|
| Humidity | 10 ... 70 % |
| Ambient temperature | -25 ... 45 °C |
| Amplification | |
|---|---|
| Sat | -5 dB typical |
| Terrestrial | 0 ... 9 dB adjustable |
| Return path | -5 ... -1 dB adjustable |
| Decoupling | |
|---|---|
| Output | > 25 dB |
| Power supply | |
|---|---|
| Mains adapter | Extern, DC 13 V / 3 A |
| Nominal voltage | 230 V |
| Frequency | 50 ... 60 Hz |
| Reception range | |
|---|---|
| Sat | 950 ... 2.150 MHz |
| Terrestrial | 87 ... 790 MHz |
| Return path | 2 ... 68 MHz |
| Technical data | |
|---|---|
| Satellite inputs | 8 |
| Terrestrial input | 1 |
| Outputs | 20 |
| Distribution length | max. 70 m |
