TechniSystem 5/8 G2 (base unit)

Multi-switch system with connection possibility of 4 ZF levels for distribution to up to 8 participants

Colour blue/white

% €129.00*

€159.00 (18.87% saved)

incl. VAT.

Made in Germany; professional multiswitch system for implementing larger cable networks in residential units, complexes, and large facilities
The professional system for Quattro LNBs features 4 satellite inputs, 1 terrestrial input, and 8 outputs
No attenuation in the satellite band, with tilt compensation
Attention: The components of the TECHNISYSTEM are not compatible with TECHNISWITCH components
Scope of delivery: TechniSat TECHNISYSTEM 5/8 G2 (basic unit), plug-in power supply (15V/1.5A), user manual

TECHNISYSTEM 5/8 G2, Power supply, Manual

This cascadable matrix for eight receivers, can be used up to eight times in one trunk. The power supply is taken from a TechniSystem G or from a Line Amplifier 5 Z / NT.

Attention: These TechniSystem 5/8 G + 5/8 K are not compatible with TechniSwitch 5/8 G and 5/8 K.

Technical Datasheet ( HTML / PDF )

html

Instruction manual

pdf

Product Information
EAN	4019588132498
Colour	blue/yellow
Item no.	0001/3249
Weight (Box)	1 kg
Weight	300 kg
Device (W x H x D)	17,2 x 11,5 x 3,2 cm
Box	17,4 x 13,5 x 10,5 cm

Ambient operating conditions
Ambient temperature	-25 ... 55 °C

Amplification
Sat	-2 ... 3 dB
Terrestrial	-4 ... -1 dB

Decoupling
Output	> 35 dB
Trunks	40 dB

General characteristics
Top features	Professionelles Multischaltersystem für Großanlagen
Top features	Ohne Dämpfung im Sat-Bereich
Top features	Mit Schräglagenentzerrung
Top features	Für Quattro-LNB
